Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen
Drum Trommel Screen

Drum Trommel Screen

Model: DYT
Mesh size: As client's demand
Motor: Ordinary motor with vibration exciter
Applicable Industry: Mining, food, chemical industry, construction, etc.
Machine Material: All carbon steel / All stainless Steel
Screen Mesh: Woven mesh 、 Perforated plate / Manganese steel mesh
Description
Parameters
Features
Application
Inquiry
Description
1.Trommel drum screen is mainly consists of motor, reducer, drum units, sealing cover, support, etc.
2.Inclination of drum equipment, motor is connected by reducer & the drum unit, the drive drum rotate around its axis.
3.When the materials go into the drum unit, due to the inclination and the rotation of drum unit, it makes qualified materials come out by the outer of trommel screen, substandard materials come out by the end of trommel screen.
Structure:
Trommel screen consist of motor,reducer,trommel device,rack,seal cover and inlet and outlet.
Parameters
Model Trommel Dia. Trommel Length Screen Segment No. Aperture Size Power Inclined Angle Handling Capacity
DYT600 φ600 2-4m 1-2 5-35mm 2.2-3kw 0-7° 1-5m³/h
DYT800 φ800 2-5m 1-3 5-40mm 3-5.5kw 0-7° 2-8m³/h
DYT1000 φ1000 2-6m 1-4 5-50mm 4-7.5kw 0-7° 5-10m³/h
DYT1200 φ1200 3-8m 1-4 5-60mm 5.5-11kw 0-7° 8-15m³/h
DYT1500 φ1500 3-10m 1-5 5-60mm 7.5-15kw 0-7° 20-50m³/h
DYT2000 φ2000 4-12m 1-5 5-75mm 7.5-18.5kw 0-7° 50-80m³/h
DYT2500 φ2500 5-12m 1-6 5-90mm 11-18.5kw 0-7° 80-150m³/h

Note: If you have any inquiry, please email us or leave your message, our engineer will timely contact with you.
Note: For more information, please directly contact us or leave your message, our engineer will timely reply you.
Features
1. It is durable and low maintenance cost, with 18 months warranty, 0 purchasing risk.
2. It is designed by your requirements, meet different handling capacity and working site.
3. It is fully enclosed by sealing structure, no dust pollution, more suit for high standard working conditions.
4. Install the automatic cleaning brush on the top of trommel screen to avoid the blockage.
5. The Screen is made of 16Mn with strong strength, good abrasion resistance and high screening efficiency for long life.
Application
1. It is durable and low maintenance cost, with 18 months warranty, 0 purchasing risk.
2. It is designed by your requirements, meet different handling capacity and working site.
3. It is fully enclosed by sealing structure, no dust pollution, more suit for high standard working conditions.
4. Install the automatic cleaning brush on the top of trommel screen to avoid the blockage.
5. The Screen is made of 16Mn with strong strength, good abrasion resistance and high screening efficiency for long life.
Customer site
Customer site
Customer site
Customer site
Customer site
Customer site
