Pharmaceutical Vacuum Conveyor Machine

Vacuum feeder is a kind of fully enclosed conveyor produced by Xinxiang Dayong, which can be used as the conveyor of medicine vacuum conveying. There is no heat generation in the working process, and it is safe and explosion-proof. The conveying capacity mainly depends on the material characteristics, viscosity, density, fluidity, etc. the conveying distance is 80m horizontally and 30m vertically, and the conveying capacity is 10t / h

Share:
Content

The vacuum feeder uses the vacuum pump to generate negative pressure air flow. When the vacuum feeder is feeding, the negative pressure generated by the vacuum will suck the material from the inlet. Then, the air is separated from the material in the filter bin of the separation container. The material falls down automatically due to gravity and is collected in the silo. Our cyclone prevents fine powder from entering the filter to improve the efficiency of the filter. When the silo is full of materials, the vacuum pump will automatically shut down and the pressure in the conveying equipment will reach balance.
